RAFI REFERENCE - Central control unit ULTRASOUND SCANNER

With its high-quality design and choice of materials, the operator panel underscores the company’s leadership in the field of cardiovascular ultrasound.

A spacious 15.6-inch touchscreen features a sophisticated user interface, complemented by a metallic finish and chrome accents. A precision laser trackball and optical encoders with fixed, backlit hubs are just a few of the many premium features.

Product: Vivid Pioneer
Industry: Cardiovascular Ultrasound
Function: Central control unit for all system functions

SCOPE OF SERVICE

At RAFI, this product is part of a proven and successful supply chain concept that involves development and manufacturing in Europe, with the option of replicating production at sites in the United States and China.

The client order includes the development and industrialization of the operator panel, the manufacture of the electronic assemblies, touchscreens, and operating elements it contains, and the final assembly of the unit for production and service needs. The overall package is complemented by a replacement-part and repair program.

KEY FEATURES AT A GLANCE

Reliable and durable product design

Complex electronic assemblies with in-depth testing
Rugged touchscreen set to device-specific parameters with sealed bezel for safe and clean interaction with the client application.
Cost-optimized optical encoders with a service life of over one million cycles
Precise laser trackball for accurate cursor control
Worker guidance systems in production

Premium look

Metallic paint on housings, key switches, and encoder caps
Chrome accents on encoder rings
Wide ambient light bar on the front panel
Gap sealing with potting compound for seamless touchscreens
